A comprehensive range of Circular LED panels available in a wealth of sizes and colour temperatures to best suit the needs of each project. The slimline design of the LuxPanel Eco Circular solutions makes it suitable for recessed mounting low ceiling voids. Featuring a white aluminium frame with a polycarbonate TPb diffuser and remote driver the range is a high-quality solution. Each product within the range can be specified in 3000K or 4000K and as fixed output or digital dimmable solution.
Slimline design suitable for recessed mounting low ceiling voids
White aluminium frame with a polycarbonate TPb diffuser and remote driver
Full range available including 120, 150, 170, 220, 300mm diameter available
3000K and 4000K CCT available in Fixed Out-put & Digital Dimmable driver modules
Remote Emergency Pack
Code | Driver Type | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Add to Spec |
---|---|---|---|---|---|
Code
ELP15W9L30
|
Driver Type
Fixed Output
|
Lumen Output (lm)
720
|
Max Wattage (W)
9
|
Efficacy (Lm/W)
80
|
|
Code
ELP15W9D30
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
720
|
Max Wattage (W)
9
|
Efficacy (Lm/W)
80
|
|
Code
ELP15W9L40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
720
|
Max Wattage (W)
9
|
Efficacy (Lm/W)
80
|
|
Code
ELP15W9D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
720
|
Max Wattage (W)
9
|
Efficacy (Lm/W)
80
|
