Platinum Surface Mini
The Luceco Platinum Surface Mini range delivers high-quality downlights in a compact form, ideal for applications where space is limited, without compromising on performance or style.
Platinum Surface Mini is a surface-mounted high-performance downlight range, offering the same sleek design and excellent performance as the standard Platinum Surface, but in a smaller housing. With an impressive CRI of >80, the Mini range provides flexible installation options including surface, suspension, or BESA mounting. Built to last, it features an IK04 rating and is backed by Luceco’s 7-year warranty.
Die-cast aluminium body designed to provide optimal thermal control with aluminium bezel and aluminium reflector
Surface high-performance downlight with efficacy up to 138 Llm/cW
Surface, suspension and BESA mounted
| Code | General Colour | Driver Type | Colour Temp (CCT) (K) | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Cutout (mm) | Add to Spec |
|---|---|---|---|---|---|---|---|---|
|
Code
LDPS15W11GS40
|
General Colour
White
|
Driver Type
Fixed Output
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
1100
|
Max Wattage (W)
8
|
Efficacy (Lm/W)
138
|
Cutout (mm)
0
|
|
|
Code
LDPS15W16GS40
|
General Colour
White
|
Driver Type
Fixed Output
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
1600
|
Max Wattage (W)
12
|
Efficacy (Lm/W)
133
|
Cutout (mm)
0
|
|
|
Code
LDPS15W25GS40
|
General Colour
White
|
Driver Type
Fixed Output
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
2500
|
Max Wattage (W)
20
|
Efficacy (Lm/W)
125
|
Cutout (mm)
0
|
|
|
Code
LDPS15W32GS40
|
General Colour
White
|
Driver Type
Fixed Output
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
3300
|
Max Wattage (W)
27
|
Efficacy (Lm/W)
122
|
Cutout (mm)
0
|
|
|
Code
LDPS15W11GD40
|
General Colour
White
|
Driver Type
Digital Dimmable
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
1100
|
Max Wattage (W)
8
|
Efficacy (Lm/W)
138
|
Cutout (mm)
0
|
|
|
Code
LDPS15W16GD40
|
General Colour
White
|
Driver Type
Digital Dimmable
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
1600
|
Max Wattage (W)
12
|
Efficacy (Lm/W)
133
|
Cutout (mm)
0
|
|
|
Code
LDPS15W25GD40
|
General Colour
White
|
Driver Type
Digital Dimmable
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
2500
|
Max Wattage (W)
20
|
Efficacy (Lm/W)
125
|
Cutout (mm)
0
|
|
|
Code
LDPS15W32GD40
|
General Colour
White
|
Driver Type
Digital Dimmable
|
Colour Temp (CCT) (K)
4000
|
Lumen Output (lm)
3300
|
Max Wattage (W)
27
|
Efficacy (Lm/W)
122
|
Cutout (mm)
0
|
Specification
2
Items
View
Add To
Additional Product Options
We offer additional product options to give ultimate control and flexibility to match any application
Remote Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's remote emergency pack provides 3 hours worth of back-up power to enable this to happen meeting all standards and regulations.
Self-Test Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's self-test emergency pack provides 3 hours worth of back-up power whilst the pack checks itself automatically to ensure that the battery and lamp in each emergency light are fully operational to meet all standards and regulations.
DALI Addressable Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's DALI addressable emergency pack provides 3 hours worth of back-up power, the pack automatically monitors itself to ensure that the battery and lamp in each emergency light are fully operational along with recording valuable data to meet all standards and regulations.
3000K Colour Temperature
3000K light provides a warmer more comforting effect that can be preferred in many of applications including certain public areas and domestic settings
