LOE12WECC-03
Opus Essence Surface Linear 1222mm Power Change 2900lm 21W (Selectable 5300lm 37W) 4000K (Selectable 3000K) Fixed Output + Emergency
Technical Data
| Code | LOE12WECC |
| Driver Type | Fixed Output + Emergency |
| Lumen Output (lm) | 2900/5300 |
| Max Wattage (W) | 21/37 |
| Efficacy (Lm/W) | 0 |
| Colour Temp (CCT) (K) | 4000 |
| CRI | >80 |
| Standard Deviations of Colour Matching | <3 |
| Base Colour | White - RAL 9016 (Traffic White) |
| Onsite Warranty | Yes |
Dimensions and Installation
| Product Depth (mm) | 85 |
| Product Width (mm) | 200 |
| Product Height (mm) | 1222 |
| IP Rating | IP40 |
| IK Rating | IK04 |
Performance & Safety
| Lifetime (h) | 50000 |
| L/B at Life | L70-B10 |
| L70 Hours (h) | 153000 |
| L80 Hours (h) | 102000 |
| Operating Temperature (C) | 0°C to +40°C |
| E-Class | Class1 |
| Power Factor | >0.9 |
