Mosi

Mosi is a durable utility bulkhead with a polycarbonate base and diffuser. The base can be specified in black or white to best suit the needs of the project. Mosi is a surface mounted solution with rear and four side conduit entry points to allow for ceiling or floor installation.

View Product Family

LBM200W7S40 02 LBM Part LU LBM200W7S40 02 0100 LA LIT

LBM200W7S40 02 LBM Part LU LBM200W7S40 02 0101 LA OFF

LBM200W7S40 02 LBM Part LU LBM200W7S40 02 0110 F OFF

LBM200W7S40 02 LBM Part LU LBM200W7S40 02 0111 F LIT

LBM200W7S40 02 LBM Part LU LBM200W7S40 02 0130 RS BASE

LBM200W7S40 02 LBM Part LU LBM200W7S40 02 0150 B BASE

LBM200W7S40 02 LBM Part LU LBM200W7S40 02 0170 LS BASE

Polycarbonate base and diffuser for increased durability

Opal prism diffuser with inbuilt LED gear tray for easy installation

Surface mounting luminaire with 4 side and 1 rear conduit entry points

Circular and square bulkhead variations available

Code	Driver Type	Base Colour	Lumen Output (lm)	Max Wattage (W)	Efficacy (Lm/W)	Add to Spec
Code LBM200W7S40	Driver Type Fixed Output	Base Colour White	Lumen Output (lm) 735	Max Wattage (W) 6	Efficacy (Lm/W) 122	Add to Spec Remove from Spec Processing
Code LBM200B7S40	Driver Type Fixed Output	Base Colour Black	Lumen Output (lm) 735	Max Wattage (W) 6	Efficacy (Lm/W) 122	Add to Spec Remove from Spec Processing
Code LBM290W11S40	Driver Type Fixed Output	Base Colour White	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing
Code LBM290W11E40	Driver Type Fixed Output + Emergency	Base Colour White	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing
Code LBM290W11S40MW	Driver Type Fixed Output + Sensor	Base Colour White	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing
Code LBM290W11E40MW	Driver Type Integral Microwave Sensor + Em	Base Colour White	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing
Code LBM290B11S40	Driver Type Fixed Output	Base Colour Black	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing
Code LBM290B11E40	Driver Type Fixed Output + Emergency	Base Colour Black	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing
Code LBM290B11S40MW	Driver Type Fixed Output + Sensor	Base Colour Black	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing
Code LBM290B11E40MW	Driver Type Integral Microwave Sensor + Em	Base Colour Black	Lumen Output (lm) 1150	Max Wattage (W) 9	Efficacy (Lm/W) 128	Add to Spec Remove from Spec Processing

Code	Driver Type	Base Colour	Lumen Output (lm)	Max Wattage (W)	Efficacy (Lm/W)	Add to Spec
Code LBM22W7S40	Driver Type Fixed Output	Base Colour Black	Lumen Output (lm) 735	Max Wattage (W) 6	Efficacy (Lm/W) 122	Add to Spec Remove from Spec Processing
Code LBM22B7S40	Driver Type Fixed Output	Base Colour Black	Lumen Output (lm) 735	Max Wattage (W) 6	Efficacy (Lm/W) 122	Add to Spec Remove from Spec Processing
