LCOT18BO18S40-03
CONTOUR BLACK RAL 9005 RECESSED LINEAR 1720MM 1800LM 18W STD
Direct Recessed continuous line of light 1800mm module
Very Efficient LEDs achieving 106Llm/W
Neutral white 4000k CCT with SDCM <3
Fixed output control gear
LCOFB fixing brackets required for continuous mounting LCOCC wiring connector required one per electrical connection
Technical Data
| Code | LCOT18BO18S40 |
| Lumen Output (lm) | 1900 |
| Max Wattage (W) | 18 |
| Efficacy (Lm/W) | 106 |
| Colour Temp (CCT) (K) | 4000 |
Dimensions and Installation
| Unpacked Depth (mm) | 1723 |
| Unpacked Width (mm) | 90 |
| Unpacked Height (mm) | 94 |
| Unpacked Net Weight (kg) | 5.344 |
| IP Rating | IP40 |
| IK Rating | IK04 |
| Cutout | L-1697 x W-67 |
Performance & Safety
| Lifetime (h) | 100000 |
| L70 Hours (h) | 100000 |
| L80 Hours (h) | 50000 |
| L90 Hours (h) | 25000 |
| E-Class | Class1 |
| UGR 4H 8H | <22 |
| Fire Rating | Not Applicable |
