} luweb p 20220421JW
ItemLifetime 100000
PackageWarranty 5
ItemIPRating IP20
ItemColourTemp 4000
ItemCRI 80
ItemUGR4H8H 19
ProductFireRating TPB
ItemComplianceUKCA True

We manufacture a wide range of high-output illuminated connectors to give you full flexibly to light up any shaped space. Ranging from 90 degree connectors to T and X connectors we've got you covered.

Aluminium extruded precision cut body with recessing flange finished in RAL9016. Low glare opal polycarbonate diffuser (Micro-prism available) with flush die-cast aluminium endcaps

Connector accessories including 90˚, T-connectors and X-connectors allowing full flexibility when designing a continuous system

Fixed Output & Digital Dimmable driver available

Code Base Colour Unpacked Depth (mm) Driver Type Lumen Output (lm) Max Wattage (W) Efficacy (Lm/W) Add to Spec
Code
LCOT9CWO12S40
Base Colour
White - RAL 9016 (Traffic White)
Unpacked Depth (mm)
330
Driver Type
Fixed Output
Lumen Output (lm)
600
Max Wattage (W)
11
Efficacy (Lm/W)
55
Add to Spec
Code
LCOT9CWO12D40
Base Colour
White - RAL 9016 (Traffic White)
Unpacked Depth (mm)
330
Driver Type
Digital Dimmable
Lumen Output (lm)
1200
Max Wattage (W)
11
Efficacy (Lm/W)
109
Add to Spec
Code
LCOT9CBO12S40
Base Colour
Black - RAL9005 (Jet Black)
Unpacked Depth (mm)
330
Driver Type
Fixed Output
Lumen Output (lm)
600
Max Wattage (W)
11
Efficacy (Lm/W)
55
Add to Spec
Code
LCOT9CBO12D40
Base Colour
Black - RAL9005 (Jet Black)
Unpacked Depth (mm)
330
Driver Type
Digital Dimmable
Lumen Output (lm)
1200
Max Wattage (W)
11
Efficacy (Lm/W)
109
Add to Spec
Specification
3 Items
View

Additional Product Options

We offer additional product options to give ultimate control and flexibility to match any application

3000K Colour Temperature

Insert 30, eg. LCOT9CWO012S30
