FTR6WCCT-01
FType Mk2 Fire Rated Downlight 4W/6W 750lm Power Change & 4Colour CCT 2700K, 3000K, 4000K, 6000K Dimmable IP65 White - Regressed
Technical Data
| Code | FTR6WCCT |
| Driver Type | Colour Change |
| Lumen Output (lm) | 485/750 |
| Max Wattage (W) | 4/6 |
| Efficacy (Lm/W) | 121/125 |
| Colour Temp (CCT) (K) | 2700, 3000, 4000, 6000 |
| Beam Angle (degrees) | 60 |
| CRI | >80 |
| Base Colour | White |
| Bezel Type | Regressed |
Dimensions and Installation
| Cutout (mm) | 76 |
| Product Depth (mm) | 75 |
| Product Width (mm) | 90 |
| Product Height (mm) | 90 |
| Product Weight (kg) | 0.192 |
Performance & Safety
| Lifetime (h) | 40000 |
| L/B at Life | L70-B50 |
| L70 Hours (h) | 40000 |
| Operating Temperature (C) | -25°C to +40°C |
| E-Class | Class1 |
| Power Factor | >0.9 |
| IK Rating | IK05 |
| Fire Rating | PartB, 30 60 90 minute, I-Joist |
| Part E Compliant | Yes |
| Part C Compliant | Yes |
