luweb 20220921JW

The Platinum Darklight range offers a low glare light effect withing a die-cast aluminium body designed to provide optimal thermal control. A high-performance range the downlights offer an efficacy of up to 115Llm/cW, with an low glare reflector type. A recessed solution with a 220m diameter, the unique swing tab design enables a quick and easy installation.

High performance low glare downlight offering UGR rating of between 13 and 17

Di-cast aluminium heat sink and bezel design provides a sturdy construction

Up to 2750 lumens, efficacy of 111Llm/cW with Fixed Output or Digital Dimmable driver options available

With unique swing tab design this recessed luminaire fits into 205mm cut-out with ease

Shallow depth removeable magnetic bezel

Code Driver Type Colour Temp (CCT) (K) Lumen Output (lm) Max Wattage (W) Efficacy (Lm/W) Cutout (mm) Add to Spec
Code
LDP20W11BS40
Driver Type
Fixed Output
Colour Temp (CCT) (K)
4000
Lumen Output (lm)
1050
Max Wattage (W)
9.5
Efficacy (Lm/W)
111
Cutout (mm)
205
Add to Spec Remove from Spec Processing
Code
LDP20W15BS40
Driver Type
Fixed Output
Colour Temp (CCT) (K)
4000
Lumen Output (lm)
1500
Max Wattage (W)
13
Efficacy (Lm/W)
115
Cutout (mm)
205
Add to Spec Remove from Spec Processing
Code
LDP20W21BS40
Driver Type
Fixed Output
Colour Temp (CCT) (K)
4000
Lumen Output (lm)
2100
Max Wattage (W)
19
Efficacy (Lm/W)
111
Cutout (mm)
205
Add to Spec Remove from Spec Processing
Code
LDP20W28BS40
Driver Type
Fixed Output
Colour Temp (CCT) (K)
4000
Lumen Output (lm)
2750
Max Wattage (W)
26
Efficacy (Lm/W)
106
Cutout (mm)
205
Add to Spec Remove from Spec Processing
