LHBC28D120-05
Ceres white RAL 9016 IP65 highbay 540mm 28000lm 200w dim 120-degree
Technical Data
| Code | LHBC28D120 |
| Driver Type | Digital Dimmable |
| Lumen Output (lm) | 28000 |
| Max Wattage (W) | 200 |
| Efficacy (Lm/W) | 140 |
| Colour Temp (CCT) (K) | 4000 |
| CRI | >80 |
| Standard Deviations of Colour Matching | <6 |
| Base Colour | White - RAL 9016 (Traffic White) |
| Onsite Warranty | Yes |
Dimensions and Installation
| Product Depth (mm) | 380 |
| Product Width (mm) | 540 |
| Product Height (mm) | 158 |
| Product Weight (kg) | 12.6 |
| IP Rating | IP65 |
| IK Rating | IK10 |
| Cutout (mm) | N/A |
Performance & Safety
| Lifetime (h) | 100000 |
| L/B at Life | L70-B50 |
| L70 Hours (h) | 119000 |
| L80 Hours (h) | 73000 |
| L90 Hours (h) | 34000 |
| Operating Temperature (C) | 0°C to +25°C |
| E-Class | Class1 |
| Power Factor | >0.9 |
| UGR 4H 8H | <30 |
