LBS1G4-01
Storm bulkhead 110mm 400 lumens
Polycarbonate base and diffuser
Efficient LEDs achieving 89Llm/W
60W GLS equivalent
Fixed output control gear
60W GLS equivalent
Technical Data
| Code | LBS1G4 |
| Driver Type | Fixed Output |
| Lumen Output (lm) | 400 |
| Max Wattage (W) | 4.5 |
| Efficacy (Lm/W) | 89 |
| Colour Temp (CCT) (K) | 4000 |
| CRI | >80 |
| Standard Deviations of Colour Matching | <6 |
| Base Colour | Grey |
Dimensions and Installation
| Unpacked Depth (mm) | 80 |
| Unpacked Width (mm) | 115 |
| Unpacked Height (mm) | 115 |
| Unpacked Net Weight (kg) | 0.246 |
| IP Rating | IP65 |
| IK Rating | IK08 |
| Cutout (mm) | N/A |
Performance & Safety
| Lifetime (h) | 30000 |
| L/B at Life | L70-B50 |
| L70 Hours (h) | 60000 |
| Operating Temperature (C) | -20°C to +25°C |
| E-Class | Class2 |
| Power Factor | >0.5 |
