LCOW06WO26ED40-03
Contour 574mm wall module 2600lumens with DALI driver finished in black
Technical Data
| Code | LCOW06WO26ED40 |
| Driver Type | Digital Dimmable |
| Lumen Output (lm) | 2600 |
| Max Wattage (W) | 21 |
| Efficacy (Lm/W) | 124 |
| Colour Temp (CCT) (K) | 4000 |
| CRI | >80 |
| Standard Deviations of Colour Matching | <3 |
| Base Colour | White - RAL 9016 (Traffic White) |
| Onsite Warranty | Yes |
Dimensions and Installation
| Product Depth (mm) | 574 |
| Product Width (mm) | 67 |
| Product Height (mm) | 104 |
| Product Weight (kg) | 1.98 |
| IP Rating | IP40 |
| IK Rating | IK04 |
| Cutout (mm) | NA |
Performance & Safety
| Lifetime (h) | 100000 |
| L/B at Life | L80-B10 |
| L70 Hours (h) | 100000 |
| L80 Hours (h) | 50000 |
| L90 Hours (h) | 25000 |
| Operating Temperature (C) | -20°C to +25°C |
| E-Class | Class1 |
| Power Factor | >0.9 |
| UGR 4H 8H | 17 |
