Luceco LuxPanel Essence
ItemLifetime 50000
PackageWarranty 5
ItemColourTemp 4000
ItemCRI 80
ProductFireRating TPB
ItemComplianceUKCA True

All sizes are manufactured in a white aluminium frame with a TPb UGR19-compliant diffuser. The Luxpanel Essence range offers an impressive 50,000-hour lifetime and a 5-year standard warranty.

Backlit LED technology with slimline 27mm depth

600 x 600 or 1200 x 600 white aluminium frame with TPb UGR 19 compliant diffuser

Recessed mounted suitable for use in 15mm or 24mm standard exposed ceiling grids

Producing a 4000K pure white CCT

Accessories include Luceco Remote Emergency Packs, Surface Frames and Suspension kits

Code Driver Type Lumen Output (lm) Max Wattage (W) Efficacy (Lm/W) Standard Deviations of Colour Matching L/B at Life Add to Spec
Code
LES66W28L40
Driver Type
Fixed Output
Lumen Output (lm)
2800
Max Wattage (W)
25.5
Efficacy (Lm/W)
110
Standard Deviations of Colour Matching
<6
L/B at Life
L70-B50
Add to Spec Remove from Spec Processing
Code
LES66W28D40
Driver Type
Digital Dimmable
Lumen Output (lm)
2800
Max Wattage (W)
25.5
Efficacy (Lm/W)
110
Standard Deviations of Colour Matching
<6
L/B at Life
L70-B50
Add to Spec Remove from Spec Processing
Code
LES66W28L30
Driver Type
Fixed Output
Lumen Output (lm)
2800
Max Wattage (W)
25.5
Efficacy (Lm/W)
110
Standard Deviations of Colour Matching
<6
L/B at Life
L70-B50
Add to Spec Remove from Spec Processing
Code
LES66W28L60
Driver Type
Fixed Output
Lumen Output (lm)
2800
Max Wattage (W)
25.5
Efficacy (Lm/W)
110
Standard Deviations of Colour Matching
<6
L/B at Life
L70-B50
Add to Spec Remove from Spec Processing
Code
LES66W35L40
Driver Type
Fixed Output
Lumen Output (lm)
3500
Max Wattage (W)
32
Efficacy (Lm/W)
109
Standard Deviations of Colour Matching
<6
L/B at Life
L70-B50
Add to Spec Remove from Spec Processing
