LuxPanel Delta Connect
The LuxPanel Delta Connect is a smart, high-efficiency lighting panel offering integrated sensing, intelligent control, and premium light quality for modern commercial environments.
The LuxPanel Delta Connect is a next-generation smart lighting panel designed for intelligent control, energy efficiency, and seamless integration. Featuring a built-in Bluetooth NLC PIR sensor, it offers motion detection, daylight harvesting, remote access, scheduling, and scene setting, no extra wiring required.
Architectural direct/indirect backlit LED Panel with slimline 57mm depth finished in RAL9016 white
Integrated Platform PIR sensor with motion sensitivity and daylight control
600x600mm white aluminium frame with TPa rated diffuser and UGR19 compliant
Recessed mounted suitable for use in 15mm or 24mm standard exposed ceiling grids
| Code | Driver Type | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Standard Deviations of Colour Matching | L/B at Life | Add to Spec |
|---|---|---|---|---|---|---|---|
|
Code
LPDC66W28LPW940PIR
|
Driver Type
Luceco Platform Wireless
|
Lumen Output (lm)
2800
|
Max Wattage (W)
20
|
Efficacy (Lm/W)
140
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L70-B50
|
|
|
Code
LPDC66W20LPW940PIR
|
Driver Type
Luceco Platform Wireless
|
Lumen Output (lm)
2000
|
Max Wattage (W)
14
|
Efficacy (Lm/W)
143
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L70-B50
|
|
|
Code
LPDC66W42LPW940PIR
|
Driver Type
Luceco Platform Wireless
|
Lumen Output (lm)
4200
|
Max Wattage (W)
29
|
Efficacy (Lm/W)
145
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L70-B50
|
|
|
Code
LPDC66W35LPW940PIR
|
Driver Type
Luceco Platform Wireless
|
Lumen Output (lm)
3500
|
Max Wattage (W)
24
|
Efficacy (Lm/W)
146
|
Standard Deviations of Colour Matching
<3
|
L/B at Life
L70-B50
|
