LPDC66W28LPW940PIR-01
Luceco LuxPanel Delta Connect LED Panel with PIR Motion Sensor, Smart Control, Bluetooth, Architectural Direct/Indirect Panel Luminaire, 600x600mm, 20W, 2800lm, 4000K
Technical Data
| Code | LPDC66W28LPW940PIR |
| Driver Type | Luceco Platform Wireless |
| Lumen Output (lm) | 2800 |
| Max Wattage (W) | 20 |
| Efficacy (Lm/W) | 140 |
| Colour Temp (CCT) (K) | 4000 |
| CRI | >90 |
| Base Colour | White - RAL 9016 (Traffic White) |
Dimensions and Installation
| Product Depth (mm) | 43 |
| Product Width (mm) | 595 |
| Product Height (mm) | 595 |
| Product Weight (kg) | 2.3 |
| IP Rating | IP40 |
| IK Rating | IK04 |
Performance & Safety
| Lifetime (h) | 70000 |
| L/B at Life | L70-B50 |
| L70 Hours (h) | 70000 |
| Operating Temperature (C) | 0°C to +40°C |
| E-Class | N/A |
| Power Factor | >0.9 |
| UGR 4H 8H | <19 |
| Fire Rating | TPA |
