LAFL118NRS6NST740-01
AMNIS FLOOD. 118,000LUM.LM, 810W, 146LM/W, 6 ROW, REMOTE NEAR STANDARD DRIVER 1-10V DIMMABLE, NARROW SHORT THROW OPTIC, 4000K,RAL7016
Technical Data
| Code | LAFL118NRS6NST740 |
| Driver Type | Fixed Output |
| Lumen Output (lm) | 100000 |
| Max Wattage (W) | 810 |
| Efficacy (Lm/W) | 123 |
| Colour Temp (CCT) (K) | 4000 |
| CRI | >70 |
| Standard Deviations of Colour Matching | <6 |
| Base Colour | Anthracite Grey - RAL 7016 |
| Onsite Warranty | Yes |
Dimensions and Installation
| Product Depth (mm) | 700 |
| Product Width (mm) | 840 |
| Product Height (mm) | 153 |
| Product Weight (kg) | 42.87 |
| IP Rating | IP66 |
| IK Rating | IK08 |
| Cutout (mm) | N/A |
Performance & Safety
| Lifetime (h) | 100000 |
| L/B at Life | L70-B10 |
| L70 Hours (h) | 178000 |
| L80 Hours (h) | 112000 |
| L90 Hours (h) | 53000 |
| Operating Temperature (C) | -20°C to +25°C |
| E-Class | Class1 |
| Power Factor | >0.95 |
