Academy
A versatile and comprehensive surface linear range perfect for any environment and setting
Academy is an all-encompassing surface linear range available in different lengths with a choice of high or low outputs. The Luceco Academy offers robustness and great aesthetics, with polycarbonate secured endcaps to ensure a quality solution, enhanced by the uniform light distribution. Academy can be surface or suspension mounted with a BESA fixing and central cable entry.
White painted steel body finished in RAL9016 with microprism polycarbonate opal diffusers. Polycarbonate secured endcaps
Available in 1200, 1500mm and 1800mm product lengths
High and low output available with efficacy up to 129 Llm/cW
Surface or suspension mounted with Besa fixing and central cable entry
| Code | Driver Type | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Add to Spec |
|---|---|---|---|---|---|
|
Code
LAC12P22S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
2200
|
Max Wattage (W)
17
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P22E40
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
2200
|
Max Wattage (W)
17
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P22D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
2200
|
Max Wattage (W)
17
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P22ED40
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
2200
|
Max Wattage (W)
17
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P22S40MW
|
Driver Type
Fixed Output + Sensor
|
Lumen Output (lm)
2200
|
Max Wattage (W)
17
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P22E40MW
|
Driver Type
Integral Microwave Sensor + Em
|
Lumen Output (lm)
2200
|
Max Wattage (W)
17
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P40S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P40E40
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P40D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P40ED40
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P40S40MW
|
Driver Type
Fixed Output + Sensor
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LAC12P40E40MW
|
Driver Type
Integral Microwave Sensor + Em
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
Specification
3
Items
View
Add To
Additional Product Options
We offer additional product options to give ultimate control and flexibility to match any application
Emergency Dimmable, Microwave & 10% Corridor Function
Corridor function is a luminaire setting that when 100% output is not required shall switch to emit only 10%, allowing a 'stand by' mode apperance whilst saving on unwanted energy usage. Many public applications use this setting to ensure light is always provided in some capacity. Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Insert ED & MW, eg. LAC12P22ED40MW
Self-Test Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's self-test emergency pack provides 3 hours worth of back-up power whilst the pack checks itself automatically to ensure that the battery and lamp in each emergency light are fully operational to meet all standards and regulations. Insert EST, eg. LAC12P22EST40
DALI Addressable Emergency
Emergency lighting is required to allow safe evacuation of an area in the event of mains failure. Luceco's DALI addressable emergency pack provides 3 hours worth of back-up power, the pack automatically monitors itself to ensure that the battery and lamp in each emergency light are fully operational along with recording valuable data to meet all standards and regulations. Insert EST, eg. LAC12P22EDED40
