Leren
Leren is a continuous architectural lighting system featuring components manufactured with an extruded aluminium body to deliver robustness
Leren is a continuous architectural lighting system featuring components manufactured with an extruded aluminium body to deliver robustness. Finished in RAL9106, and optimised for lighting office, education and other commercial spaces, Leren is a flexible and adaptable range featuring a wealth of variants. Its 100k hour lifespan ensures it can stay in situ for many years ahead.
Architectural extruded aluminium body with robust construction finished in RAL9016 two module down one module up for direct: indirect lighting
Optimised for lighting offices and education spaces the 1500mm module is available in 4000-7500Lumens with up to 122 Llm/cW. Blank modules also available.
Suspension mounted via 1.5M suspension kit supplied
| Code | Driver Type | Lumen Output (lm) | Max Wattage (W) | Efficacy (Lm/W) | Add to Spec |
|---|---|---|---|---|---|
|
Code
LER15W40S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LER15W40D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LER15W40E40
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LER15W40ED40
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
4000
|
Max Wattage (W)
31
|
Efficacy (Lm/W)
129
|
|
|
Code
LER15W52S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
5200
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
130
|
|
|
Code
LER15W52D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
5200
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
130
|
|
|
Code
LER15W52E40
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
5200
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
130
|
|
|
Code
LER15W52ED40
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
5200
|
Max Wattage (W)
40
|
Efficacy (Lm/W)
130
|
|
|
Code
LER15W75S40
|
Driver Type
Fixed Output
|
Lumen Output (lm)
7500
|
Max Wattage (W)
59
|
Efficacy (Lm/W)
127
|
|
|
Code
LER15W75D40
|
Driver Type
Digital Dimmable
|
Lumen Output (lm)
7500
|
Max Wattage (W)
59
|
Efficacy (Lm/W)
127
|
|
|
Code
LER15W75E40
|
Driver Type
Fixed Output + Emergency
|
Lumen Output (lm)
7500
|
Max Wattage (W)
59
|
Efficacy (Lm/W)
127
|
|
|
Code
LER15W75ED40
|
Driver Type
Digital Dimmable + Emergency
|
Lumen Output (lm)
7500
|
Max Wattage (W)
59
|
Efficacy (Lm/W)
127
|
